Specifications for Signature doorknobs
By default, a doorknob refers to a turning mortice knob used on internal doors to operate a latch mechanism via an 8mm square spindle. Our turning doorknobs (or passage doorknobs) are assembled with a round back-plate which is secured to the door with attractive wood screws in solid brass, plated to match the finish of the back-plate.
It is also possible to order Signature doorknobs in a Fixed version, to be used either as a dummy on the slave door (of double doors), or on Push-Pull doors. Fixed doorknobs are also used on Wardrobes or where a large Pull knob is required. Our fixed knobs are threaded for M10 thread and can be installed back-to-back.
Fixed doorknobs can be supplied assembled with a round back-plate like turning mortice knobs. Alternatively, we can supply them without, in which case we modify the base so that it sits flush on the door. This configuration is especially recommended when fixed doorknobs are being used on glass doors.
We can provide a glass installation set including soft washers and a sleeve to house the fixing bolt.
Related pages
Cristalle doorknobs
Monogrammed doorknobs
Sensation doorknobs
Signature cabinet knobs
Signature lever handles
Signature centre knobs
Back to Signature collection
Description:
Ultra-contemporary doorknob, softened by a gold accent
Material & Finish:
bronze & hand-polished cristalle resin
Finishes available:
polished gold & cristalle
satin gold & cristalle
Dimensions: 55 x 57mm; projection 65mm,
minimum clearance 50mm
Specifications:
• Can be made either as mortice doorknob with 8mm spindle hub; or as fixed doorknob with M10 thread
• Fixed doorknob can be supplied without a back-plate to fit on glass or mirror
• Can be made to work in conjunction with rim lock
Description:
Gold doorknob with a contemporary twist, encapsulating the spirit of Haute Deco
Material & Finish: bronze & hand-polished cristalle resin
Finishes available:
polished gold & cristalle
satin gold & cristalle
Dimensions: available in 3 sizes to suit regular and oversize doors
• Standard Coupole: Ø 60mm; projection 72mm, minimum clearance 40mm
• Large Coupole: Ø 72mm; projection 82mm, minimum clearance 50mm
• Maxi Coupole: Ø 84mm; projection 90mm, minimum clearance 55mm
Specifications:
• Can be made either as mortice doorknob with 8mm spindle hub; or as fixed doorknob with M10 thread
• Fixed doorknob can be supplied without a back-plate to fit on glass or mirror
• Can be made to work in conjunction with rim lock
Description:
Yin and Yang doorknob, combining a soft gold accent with translucent cristalle resin
Material & Finish: bronze & hand-polished cristalle resin
Finishes available:
polished gold & cristalle
satin gold & cristalle
Dimensions: 55 x 57mm; projection 67mm,
minimum clearance 50mm
Specifications:
• Can be made either as mortice doorknob with 8mm spindle hub; or as fixed doorknob with M10 thread
• Fixed doorknob can be supplied without a back-plate to fit on glass or mirror
• Can be made to work in conjunction with rim lock
Description:
combining ethereal cristalle resin with a satin gold accent, this streamlined doorknob has all the makings of a new classic
Material & Finish:
brass & hand-polished cristalle resin
Finishes available:
polished gold & cristalle
satin gold & cristalle
Dimensions: Ø70mm; projection 59mm; minimum clearance 55mm
can also be ordered as fixed doorknob in the following configurations:
• paired with mortice doorknobs on double doors, front or back-to-back fixing
• with or without back-plates on wardrobes
• for installation on glass, mirror and shower doors: no back plate and flush neck detail
Specifications:
• Can be made either as mortice doorknob with 8mm spindle hub; or as fixed doorknob with M10 thread
• Fixed doorknob can be supplied without a back-plate to fit on glass or mirror
• Can be made to work in conjunction with rim lock
Description:
Contemporary square doorknob with dark bronze feature
Material & Finish:
bronze & hand-polished cristalle resin
Dimensions: 55 x 57mm; projection 65mm,
minimum clearance 50mm
Specifications:
• Can be made either as mortice doorknob with 8mm spindle hub; or as fixed doorknob with M10 thread
• Fixed doorknob can be supplied without a back-plate to fit on glass or mirror
• Can be made to work in conjunction with rim lock
Description:
Contemporary-classic doorknob with warm bronze undertones
Material & Finish: bronze & hand-polished cristalle resin
Dimensions: available in 3 sizes to suit regular and oversize doors
• Standard Coupole: Ø 60mm; projection 72mm, minimum clearance 40mm
• Large Coupole: Ø 72mm; projection 82mm, minimum clearance 50mm
• Maxi Coupole: Ø 84mm; projection 90mm, minimum clearance 55mm
Specifications:
• Can be made either as mortice doorknob with 8mm spindle hub; or as fixed doorknob with M10 thread
• Fixed doorknob can be supplied without a back-plate to fit on glass or mirror
• Can be made to work in conjunction with rim lock
Description:
Squaring the circle with a bronze accent
Material & Finish: antique bronze & cristalle
bronze & hand-polished cristalle resin
Dimensions: 55 x 57mm; projection 67mm,
minimum clearance 50mm
Specifications:
• Can be made either as mortice doorknob with 8mm spindle hub; or as fixed doorknob with M10 thread
• Fixed doorknob can be supplied without a back-plate to fit on glass or mirror
• Can be made to work in conjunction with rim lock
Description:
Haute Deco's latest classic doorknob, stunning in patinated bronze
Material & Finish: cristalle and antique bronze
brass & hand-polished cristalle resin
Dimensions: Ø70mm; projection 59mm; minimum clearance 55mm
Specifications:
• Turning mortice doorknob (or passage) with square hub for 8mm spindle
• Mortice doorknobs are supplied attached to a back-plate (rose) with a cerclip
• Signature Mortice doorknobs are not spring-loaded
• Mortice doorknobs can be customised for use on rim-locks in which case they have no back-plate
• Also available as Fixed doorknob to be used as Pull or Dummy
• Fixed doorknob can be supplied wither with or without a back-plate
• When supplied without a back-plate, the neck is modified to sit flush on the door or glass
• Fixed doorknobs are threaded in M10
• We can supply a glass/mirror fixing kit consisting of a nylon sleeve and soft washers
Description:
Contemporary doorknob oozing with character, with a nickel accent set within a cube of translucent cristalle resin
Material & Finish:
bronze & hand-polished cristalle resin
Finishes available:
polished nickel & cristalle
satin nickel & cristalle
Dimensions: 55 x 57mm; projection 65mm,
minimum clearance 50mm
Specifications:
• Can be made either as mortice doorknob with 8mm spindle hub; or as fixed doorknob with M10 thread
• Fixed doorknob can be supplied without a back-plate to fit on glass or mirror
• Can be made to work in conjunction with rim lock
Description:
Iconic doorknob combining a crisp nickel accent with the fluid translucency of cristalle resin
Material & Finish: bronze & hand-polished cristalle resin
Finishes available:
polished nickel & cristalle
satin nickel & cristalle
Dimensions: available in 3 sizes to suit regular and oversize doors
• Standard Coupole: Ø 60mm; projection 72mm, minimum clearance 40mm
• Large Coupole: Ø 72mm; projection 82mm, minimum clearance 50mm
• Maxi Coupole: Ø 84mm; projection 90mm, minimum clearance 55mm
Specifications:
• Can be made either as mortice doorknob with 8mm spindle hub; or as fixed doorknob with M10 thread
• Fixed doorknob can be supplied without a back-plate to fit on glass or mirror
• Can be made to work in conjunction with rim lock
Description:
Squaring the circle, a sleek and radiant doorknob with attitude
Material & Finish: bronze & hand-polished cristalle resin
Finishes available:
polished nickel & cristalle
satin nickel & cristalle
Dimensions: 55 x 57mm; projection 67mm,
minimum clearance 50mm
Specifications:
• Can be made either as mortice doorknob with 8mm spindle hub; or as fixed doorknob with M10 thread
• Fixed doorknob can be supplied without a back-plate to fit on glass or mirror
• Can be made to work in conjunction with rim lock
Description:
In Haute Déco's take on an Anglo-American classic, the traditional drum doorknob takes on a new persona: streamlined and lightened by using cristalle instead of solid metal, it combines the lightness of glass with a subtle metallic accent
Material & Finish: brass & hand-polished cristalle resin
Finishes available:
polished nickel & cristalle
Dimensions: Ø70mm; projection 59mm; minimum clearance 55mm
Specifications:
• Can be made either as mortice doorknob with 8mm spindle hub; or as fixed doorknob with M10 thread
• Fixed doorknob can be supplied without a back-plate to fit on glass or mirror
• Can be made to work in conjunction with rim lock
Description:
Cubic doorknob softened by the warm glow of rose bronze
Material & Finish:
bronze & hand-polished cristalle resin
Finishes available:
polished rose bronze & cristalle
satin rose bronze and cristalle resin
Dimensions: 55 x 57mm; projection 65mm,
minimum clearance 50mm
Specifications:
• Can be made either as mortice doorknob with 8mm spindle hub; or as fixed doorknob with M10 thread
• Fixed doorknob can be supplied without a back-plate to fit on glass or mirror
• Can be made to work in conjunction with rim lock
Description:
Uber-chic doorknob with hidden depth in subtle rose bronze
Material & Finish:
bronze & hand-polished cristalle resin
Finishes available:
polished rose bronze & cristalle
satin rose gold and cristalle resin
Dimensions: available in 3 sizes to suit regular and oversize doors
• Standard Coupole: Ø 60mm; projection 72mm, minimum clearance 40mm
• Large Coupole: Ø 72mm; projection 82mm, minimum clearance 50mm
• Maxi Coupole: Ø 84mm; projection 90mm, minimum clearance 55mm
Specifications:
• Can be made either as mortice doorknob with 8mm spindle hub; or as fixed doorknob with M10 thread
• Fixed doorknob can be supplied without a back-plate to fit on glass or mirror
• Can be made to work in conjunction with rim lock
Description:
Yin and Yang doorknob with rose bronze accent
Material & Finish: bronze & hand-polished cristalle resin
Finishes available:
polished rose bronze & cristalle
satin rose bronze and cristalle resin
Dimensions: 55 x 57mm; projection 67mm,
minimum clearance 50mm
Specifications:
• Can be made either as mortice doorknob with 8mm spindle hub; or as fixed doorknob with M10 thread
• Fixed doorknob can be supplied without a back-plate to fit on glass or mirror
• Can be made to work in conjunction with rim lock
